Category: Plotting machine
Brand:
Model: JLGP-I-F
Views: 2372
Scope:
High speed drawing achine performance parameters and technical indicators
Model | JLGPS-I |
Working Area | 1070*760MM |
Drive style | Import steel belt transmission |
Fix up type of medium | Vacuum absorb |
Drawing pen type | Ball pen, ink pen |
Operating surroundings | 2~40℃，35~80%RH |
Supply power | 220V 50HZ 10A |
Drawing accuracy | 0.05MM |
Rep-site accuracy | 0.02MM |
Instruction system | International standard: compatible with the CDR, CAD and other software |
The control software | Jialuo laser cutting&Engrave control system（En&Chinese version) |
1、The machine can be offline by operation,it can put any convenient place,adopting a large capacity memory and it can transport batch files;
2、Adopting the steel belt's delivery,lower noise,high accuracy；
3、The good performance dust-sproof design, the small maintenance;
4、Using vacuum absorb for fixed up the papers;
5、It can plot on the papers,can proof for lower than 350gsm papers and also draw on the wood boards directly.proofing high accuracy；
6、High accuracy, high speed, longer life;
7、It can be compatible CAD software;
8、Suitable for laser die-mould factory,printing factory,shoe factory,garment factory,suitcase and handbag factory;
9、It's better for price and characters compare with other similar products in the world;
